The TruTool C 160 12V LiHD rechargeable battery with integrated chip clipper for two-handed operation is ideal for notching work and interior cutouts of up to 1.6 mm in mild steel and 1.2 mm in stainless steel. It enables you to clip chips at any point. The cuts are free of deformation and of high quality, and the 4.0 Ah / 12V LiHD rechargeable battery guarantees long runtimes.
Applications:
- Flat sheet: For cutting and trimming flat sheets. For radial and interior cutouts as well as notching.
- Profiles: For cutting C-L-U profiles and longitudinal cuts in profile sheets.
- Tubes: For cutting tubes.
- Checker plate: For cutting checker plates. For radial and interior cutouts.
- Corrugated sheet metal: For cutting corrugated sheet metal. For radial and interios cutouts.
- Flat sheet: For cutting and trimming flat sheets. For radial and interior cutouts as well as notching.
- Profiles: For cutting C-L-U profiles and longitudinal cuts in profile sheets.
- Tubes: For cutting tubes.
- Checker plate: For cutting checker plates. For radial and interior cutouts.
- Corrugated sheet metal: For cutting corrugated sheet metal. For radial and interios cutouts.
| Maximum sheet thickness: | |
| Maximum sheet thickness, steel 400 n/mm² | 1.6 mm |
| Maximum sheet thickness, steel 600 n/mm² | 1,2 mm |
| Maximum sheet thickness, aluminium up to 250 n/mm² | 2 mm |
| Spiral duct, steel 400 n/mm² | 4 x 0,75 mm |
| Radi | |
| Smallest radius | 40 mm |
| General | |
| Working speed | 5 m/min - 9 m/min |
| Stroke rate at nominal load | 3520 1/min |
| Stroke rate during idle run | 5500 1/min |
| Starting hole diameter | 15 mm |
| Voltage | 12 V |
| Weight | |
| Weight (with 4 Ah rechargeable battery) | 1,6 kg |
